BAIXIANG MOTOR CO.,LTD.
W.E1031R/W.E2031R
Volt：12V/24V
No-load current：2A/≤1.2A
No load speed：50±10%rpm
Load current：≤7A /≤4A
Load speed：40±10%rpm
Working torque：4N.m/5N.m
Brake torque：≥18N.m
Intensity of the gear：25N.m
Working temperature：-20℃-60℃
Noise：≤55dB
DIrection of rotation：Red wire+ Clockwise Rotation (CW)
Green wire+Counter Clockwise Rotation(CCW)
No-load current：2A/≤1.2A
No load speed：50±10%rpm
Load current：≤7A /≤4A
Load speed：40±10%rpm
Working torque：4N.m/5N.m
Brake torque：≥18N.m
Intensity of the gear：25N.m
Working temperature：-20℃-60℃
Noise：≤55dB
DIrection of rotation：Red wire+ Clockwise Rotation (CW)
Green wire+Counter Clockwise Rotation(CCW)
| Volt | 12V | 24V | |
| No-load current | 2A | ≤1.2A | |
| No load speed | 50±10%rpm | 50±10%rpm | |
| Load current | ≤7A | ≤4A | |
| Load speed | 40±10%rpmi | 40±10%rpm | |
| Working torque | 4N.m | 5N.m | |
| Brake torque | ≥18N.m | ≥18N.m | |
| Intensity of the gear | 25N.m | 25N.m | |
| Working temperature | -20℃-60℃ | -20℃-60℃ | |
| Noise | ≤55dB | ≤55dB | |
| DIrection of rotation: Red wire+ Clockwise Rotation (CW) Green wire+Counter Clockwise Rotation(CCW) | |||
